THERA-MAX 2.5HP 2 SPEED BASELESS PUMP FOR JACUZZI AND SUNDANCE SPAS Only
This pump is a Jacuzzi / Sundance, Baseless, TheraMax, 48FR, 2.5HP, 2SP, 230V that measures about 3" across the threads..
The amperage is 10.0-12.0 Amps on high speed and 3.0 Amps on low speed and this pump will work as a one or speed pump.. Note: This Pump will Only Work in Jacuzzi and Sundance Hot Tubs that have 45 Degree Wet Ends.. DO NOT order this pump for any other application as it will not work....
THIS PUMP IS USED WITH THIS MOUNTING BASE: Base Mounting Bracket, Pump, LX, Sundance, Jacuzzi, 48 Frame
| Motor Voltage | 230v |
| Speed | 2 Speed (2-Spd) |
| Motor Amperage/Wattage | 10-12.0A/3.3A |
| Horsepower | 2.5hp |
| Manufacturer | Balboa Water Group |
| Pump Model | TheraMax |
| Suction Pipe Size | 2" |
| Suction Connection Type | Male Buttress Thread (mbt) |
| Suction Style | Center |
| Discharge Pipe Size | 2" |
| Discharge Connection Type | Male Buttress Thread (mbt) |
| Discharge Style | Side |
| Motor Frame | 48 Frame Thru-Bolt |
| Drain Plug Location | 6,9 o`clock |
